Supplies & Handling

bizhub PRO 1050P 4-7

4.1.2 Loading Tabbed Sheets in Tray

Tabbed sheets can be used if the tray paper size is specified as tabbed

sheets in the Tray Setting. Follow the procedure below to supply the tray with

tabbed sheets.

Example: 9 Tabbed sheets loaded in postition for 3 finished sets.

1 Withdraw the tray.

The tray paper size should be specified as tabbed sheets.

Note

Refer to “Paper Setting Outlines” on page 8-3 details of Tray Setting.

2 Open the paper feed roller.

3 Place paper on the tray.

Place paper referring to the illustration shown above.

Reminder

Do not load above the limit level on the side guide plate.

Loaded in Tray Loaded in Tray

1 or 2 3,4 or 5

3 finished sets

1st TAB

2nd TAB

3rd TAB

1st TAB

2nd TAB

3rd TAB

1st TAB

2nd TAB

3rd TAB
