Preparation for Use
2-6 bizhub PRO 1050P
2.1.3 Control Panel Layout
No. Part name Description
1 Sub Power Switch turns machine power on/off when pressed.
2 Keypad enters numeric values.
3 Stop ceases the printing sequence
4 Start activates printing.
5 Start LED lights in green when machine operation is available, and
turns red if any operation cannot be started.
6 Access sets the machine to allow printing only when the User Au-
thentication/Volume Track password is entered.
7 Mode Check displays a screen showing all settings that are selected
for the current job.
8 Utility/Counter displays the Utility Menu Screen / Counter Screen or ac-
cesses porgramming modes for setting special functions.
9 Accessibility adjusts the response time when touch panel keys or con-
trol panel keys are pressed.
10 Help displays a screen with help for the currently selected
function.
13
12
11
10
9
87 6 5 4
3
2
1
15
14
16
To Next Page
