Printing Operation
5
bizhub PRO 1050P 5-3
5 Printing Operation
5.1 Machine Status Screen
The Machine Status Screen displays when machine operation becomes
available after warm-up, or when any printing job has been completed.
12
3
5
68
10
12
13
4
7
11
9
No. Part name Description
1 JOB LIST tab is touched to display the Job List Screen.
2 MACHINE tab is touched to display the Machine Status Screen, and
blinks in red when machine trouble occurs.
3 Count/Set indicator indicates the print quantity entered from the control panel
keypad, and also indicates the print count on the left of the
set count while printing.
4 Tray setting list displays the paper setting made for each tray, and also dis-
plays the paper sizes loaded in the Post inserter. The cur-
rently selected tray will be indicated in different color.
5 Job list displays the current status of the jobs to be operated on the
machine.
6 Controller key is touched to set the controller.
To Next Page
