21 TECHNICAL DATA 208
License plate lamp LED
21.7 Tires
Front tires Rear tires
110/70 R 17 M/C 54S TL
MRF revz FC
150/60 R 17 M/C 66S TL
MRF revz C
Additional information is available in the Service section under:
http://www.ktm.com
21.8 Fork
Fork part number 90101000044
Fork WP Suspension
Fork length 736 mm (28.98 in)
Fork oil 450 ml (15.21 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 249)
21.9 Shock absorber
Shock absorber part number 90604010000
Shock absorber WP Suspension
Spring preload
Standard 3 clicks
Full payload 6 clicks
Static sag 15 mm (0.59 in)
Riding sag 45… 50 mm (1.77… 1.97 in)
Fitted length 300 mm (11.81 in)
21.10 Chassis tightening torques
Exhaust clamp - 10 Nm (7.4 lbf ft) –
Screw, chain guard EJOT PT
®
4 Nm (3 lbf ft) –
Screw, headlight EJOT PT
®
4 Nm (3 lbf ft) –
Remaining screws, chassis M4 4 Nm (3 lbf ft) –
Screw, EFI control unit M4 4 Nm (3 lbf ft) –
Screw, trim, subframe, bottom M4 2 Nm (1.5 lbf ft) –
Remaining nuts, chassis M5 3 Nm (2.2 lbf ft) –
Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –
Screw, brake fluid reservoir of rear
brake
M5 6 Nm (4.4 lbf ft)
Loctite
®
243â„¢
Screw, fuel pump M5 5 Nm (3.7 lbf ft) –
Screw, fuel tank closure flange M5 3 Nm (2.2 lbf ft) –
Screw, fuel tank cover M5 4 Nm (3 lbf ft) –
Screw, fuel tank trim M5 5 Nm (3.7 lbf ft) –
Screw, license plate holder M5 11 Nm (8.1 lbf ft) –
Screw, rollover sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243â„¢
Screw, side stand switch M5 5 Nm (3.7 lbf ft)
Loctite
®
243â„¢
Screw, spoiler M5 5 Nm (3.7 lbf ft) –
Screw, subframe cover, bottom M5 5 Nm (3.7 lbf ft)
Loctite
®
243â„¢
Screw, windshield M5 3 Nm (2.2 lbf ft) –
Nut, foot brake lever adjustment M6 9 Nm (6.6 lbf ft) –
Nut, radiator M6 5 Nm (3.7 lbf ft) –
Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
