5-3
FTP Settings Display
Setting Description Default
FTP server Specify whether to use the FTP server or not.
FTP connections from external devices will not be possible if the
Do not use
Option is selected.
Do not use
Port No.
*1
,
*2
Set the FTP port number of the built-in EtherNet/IP port. This set-
ting does not normally need to be changed.
The FTP control port is set here. The FTP data transfer port is al-
ways port 20.
21
Login name
*1
Set the login name to externally connect to the built-in EtherNet/IP
port via FTP
.
(You can use up to 12 alphanumeric characters.)
*3
None
Password
*1
Set the password to externally connect to the built-in EtherNet/IP
port via FTP
.
(You can use 8 to 32 alphanumeric characters.)
*3
None
*1. These settings are required when the Use Option is selected for the FTP server.
*2. The following ports are used by the system and cannot be set by the user: 20, 23, 25, 80, 110, 9610, and
44818.
*3. The login name and password are case sensitive.
Additional Information
Refer to S
ection 11 FTP Server on page 11-1 for details on the FTP server.
5 Sysmac Studio Settings for the Built-in EtherNet/IP Port
5-9
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
5-3 FTP Settings Display
5
