7-2-13
Clearing the Device Parameters
You can clear the tag data link settings (or return them to their factory settings) that are saved in the
registered EtherNet/IP device.
The following shows how to clear tag data link parameters. For details on how to connect to the net-
work from the Network Configurator
, refer to 7-2-8 Connecting the Network Configurator to the Net-
work on page 7-52.
Precautions for Correct Use
For a CPU Unit with Unit Version 1.10 or Later
•
Use the Network Configurator version 3.58 or higher to perform the following procedure to
clear the tag data link settings.
• If you perform the following procedure from the Network Configurator version 3.57 or lower,
the tag data link settings are not cleared. Refer to Additional Information in this section for the
procedure to clear the tag data link settings from the Network Configurator version 3.57 or
lower.
1 Connect the Network Configurator to the network.
2 Select the icon of the device from which you want to clear the device parameters.
In the following example, two nodes are selected: 192.168.250.1 and 192.168.250.2. T
o select
multiple nodes, press and hold the Shift Key while you select additional icons.
3 Select Device - Reset.
Y
ou can also right-click the icon and select Reset from the pop up menu.
4 The following dialog box is displayed.
7 Tag Data Link Functions
7-71
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
7-2 Setting Tag Data Links
7
7-2-13 Clearing the Device Parameters
