Omron NX102-12 Series User Manual

1-5
EtherNet/IP Communications Proce-
dures

Basic Operation
1
Wire the Ethernet network with twisted-pair cable. Section 2 Installing Ethernet Net-
works on page
2-1
↓
2
Set the built-in EtherNet/IP port IP address with the Sysmac
Studio.
Section 4 Determining IP Ad-
dresses on page
4-1
1. Use the Sysmac Studio to create a new project.
2. Set the local IP address in one of the following ways:
• Defaults:
NX701 CPU Unit
Built-in EtherNet/IP port 1 : 192.168.250.1
(subnet mask = 255.255.255.0)
Built-in EtherNet/IP port 2 : 192.168.251.1
(subnet mask = 255.255.255.0)
NX102 CPU Unit
Built-in EtherNet/IP port 1 : 192.168.250.1
(subnet mask = 255.255.255.0)
Built-in EtherNet/IP port 2 : 192.168.251.1
(subnet mask = 255.255.255.0)
NX1P2 CPU Unit Built-in EtherNet/IP port : 192.168.250.1
(subnet mask = 255.255.255.0)
NJ-series CPU Unit Built-in EtherNet/IP port
• Set any IP address.
• Obtain from the BOOTP server
.
↓
3
Perform a communications test with a PING command from a
computer
.
Section 6 Testing Communica-
tions on page 6-1
↓
4
Use the Sysmac Studio to set the initial settings of the Ether-
Net/IP Function Module.
Section 5 Sysmac Studio Set-
tings for the Built-in EtherNet/IP
Port on page 5-1
• Set the TCP/IP settings and Ethernet settings as required.

Using Tag Data Links
1
Import the variable settings for the tags that were created on
the Sysmac Studio to the Network Configurator
.
7-2-4 Creating Tags and Tag Sets
on page 7-23
↓
2
Use the Network Configurator to create the tag data link table. Section 7 Tag Data Link Func-
tions on page
7-1
• Create the network configuration.
• Set the tags, tag sets, and connections.
↓
3
Connect the Network Configurator online.
↓
4
Download the tag data link setting.
↓
1 Introduction
1-28
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)

Omron NX102-12 Series Specifications

General

Brand	Omron
Model	NX102-12 Series
Category	Controller
Language	English
