Omron NX102-12 Series User Manual

11-2
FTP Server Function Details
11-2-1
Supported Files
The file system in the Controller that can be accessed by the built-in EtherNet/IP port includes files in
an SD Memory Card mounted in the CPU Unit.
The directory tree is shown below.
/: r
oot
MEMCARD1:SD
usr
bin
dev
Used by system
A connection is initially made to the root directory.
Additional Information
• The date of the MEMCARD1 directory displayed for ls, dir, and mkdir commands in the root
directory is the date of the file system volume label.
•
The login date is displayed for MEMCARD1 if a volume label has not been created.
11-2-2
Connecting to the FTP Server
Input the FTP login name and password to login to the built-in EtherNet/IP port from an FTP client ap-
plication. Use the Built-in EtherNet/IP Port Settings in the Sysmac Studio to set the FTP login name
and password.
Additional Information
When a general-purpose FTP application is used, you can use a graphical user interface similar
to Explorer to transfer and read files.

Login Name and Password Setting
The FTP login name and password are not set by default.
Use the Built-in EtherNet/IP Port Settings to set any login name and password.

Login Messages
Status Message
Normal connection 220 xxx.xx.xx.xx FTP server ready.
xxx.xx.xx.xx: CPU Unit model (example: NJ501-1300)
Connected to maximum
number of connections (6)
530 FTP server busy, Goodbye.

Restrictions on Login Name and Password Setting
The following restrictions apply to login names and passwords.
•
Only single-byte alphanumeric characters can be used for login names and passwords. The login
name and password are case sensitive.
11 FTP Server
11-4
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
