Omron NX102-12 Series User Manual

Outline View Detail View
Unit Versions of CPU Units and Sysmac Studio Versions
The functions that are supported depend on the unit version of the NJ/NX-series CPU Unit. The ver-
sion of Sysmac Studio that supports the functions that were added for an upgrade is required to use
those functions.
Refer to the NJ/NX-series CPU Unit Software User’s Manual (Cat. No. W501) for the relationship be-
tween the unit versions of CPU Units and the Sysmac Studio versions, and for the functions that are
supported by each unit version.
Unit Versions of CPU Units and Peripheral Tool Versions
When you set tag data links for the built-in EtherNet/IP port on an NJ/NX-series CPU Unit, use the
versions of the Network Configurator and the Sysmac Studio that are given in the following table.
OK: Supported, ---: Not supported
CPU Unit Network Configurator for EtherNet/IP Sysmac Studio
Model Version
Ver.
3.3x
or
lower
Ver.
3.40
Ver.3.
50 or
3.51
Ver.
3.53
to
3.58
Ver.
3.59
to
3.60
Ver.
3.61
to
3.63
Ver.
3.64 or
higher
Ver.
1.09
or
lower
Ver.
1.10
to
1.12
Ver.
1.13
to
1.16
Ver.
1.17
to
1.22
Ver.
1.23
or
higher
NJ501 Ver.
1.00 to
1.02
---
OK OK OK OK OK OK
---
OK OK OK OK
NJ301 Ver.
1.01 to
1.02
--- ---
OK OK OK OK OK
---
OK OK OK OK
NJ501
NJ301
Ver.
1.03 or
higher
--- --- ---
OK OK OK OK
---
OK OK OK OK
NJ101
NX701
Ver.
1.10 or
later
--- --- --- ---
OK OK OK
--- ---
OK OK OK
NX1P2 Ver.
1.13 or
later
--- --- --- --- ---
OK OK
--- --- ---
OK
¡
*1
NX102 Ver.
1.30 or
later
--- --- --- --- --- ---
OK
--- --- --- ---
OK
*1.
Use an NX1P2-9B£££££ CPU Unit with Sysmac Studio version 1.30 or higher.
Versions
26
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
