1-3
Built-in EtherNet/IP Port
1-3-1
Specifications
Item
Specifications
NX701-£££
£
NX102-£££
£
NX1P2-££
££££
NJ501-££££
NJ301-££££
NJ101-£££
£
Unit version
1.10 or later
Unit version
1.30 or later
Unit version
1.13 or later
Unit version
1.00 to 1.02
Unit version
1.03 or later
Unit version
1.10 or later
Communications protocol TCP/IP or UDP/IP
Supported services
Sysmac Studio connection, tag data link, CIP message communications, socket services, FTP
server
, FTP client, automatic clock adjustment (NTP client), SNMP agent, DNS client, and
BOOTP client
--- Packet Filter ---
Number of ports
2 (IP routing function support-
ed)
1
Physical layer
100Base-TX,
10Base-T or
1000Base-T
(1000Base-T
or 100Base-
TX is recom-
mended.)
*1
100Base-TX or 10Base-T (100Base-TX is recommended.)
*1
Transmission
specifications
Media access
method
CSMA/CD
Modulation Baseband
Transmission
paths
Star form
Baud rate
1,000 Mbps
(1000Base-T)
100 Mbps (100Base-TX)
Transmission me-
dia
Shielded twisted-pair (STP) cable, Category 5, 5e, or higher
Transmission dis-
tance
100 m max. (distance between hub and node)
Number of cas-
cade connections
There is no limitation when an Ethernet switch is used.
CIP service:
T
ag data links
(cyclic commu-
nications)
Number of con-
nections
256 per port
(total of 512
with two
ports)
32 per port
(total of 64
with two
ports)
32
Packet interval
(refresh cycle)
0.5 to 10,000
ms in 0.5-ms
increments
1 to 10,000
ms in 1-ms
increments
2 to 10,000
ms in 1-ms
increments
10 to 10,000
ms in 1-ms
increments
1 to 10,000 ms in 1-ms incre-
ments
Packet intervals can be set independently for each connection. (Data is refreshed over the net-
work at preset intervals and the refresh cycle does not depend on the number of nodes.)
1 Introduction
1-8
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
