Functional Comparison of EtherNet/IP
Ports on NJ/NX-series CPU Units and
Other Series
OK: Supported, ---: Not supported
Item
Built-in
EtherNet/
IP port
on NX701
CPU Unit
Built-in
EtherNet/
IP port
on NX102
CPU Unit
Built-in
EtherNet/
IP port
on
NX1P2
CPU Unit
Built-in
EtherNet/
IP port
on NJ-
series
CPU Unit
CJ-series
Ethernet
Unit
EtherNet/IP Unit (built-in port on
CJ2 CPU Unit)
Unit ver-
sion 1.0
Unit ver-
sion 2.0
Unit ver-
sion 2.1
Tag data link commu-
nications service
OK OK OK OK
---
OK OK OK
CIP message commu-
nications service
OK OK OK OK
---
OK OK OK
IP routing
OK OK
--- --- --- --- --- ---
Socket service
OK OK OK OK OK
--- --- ---
FTP server
OK OK OK OK OK
---
OK OK
FTP client
OK OK OK OK
--- --- --- ---
Mail send/receive --- --- --- ---
OK
--- --- ---
Web functions --- --- --- ---
OK
--- --- ---
Automatic adjustment
of PLC/Controller's in-
ternal clock
OK OK OK OK OK
---
OK OK
Error history
OK
*1
OK
*1
OK
*1
OK
*1
OK OK OK OK
Response to PING
command
OK OK OK OK OK OK OK OK
SNMP/SNMP trap
OK OK OK OK
--- ---
OK OK
CIDR function for IP
addresses
OK OK OK OK
--- ---
OK OK
Online connection via
EtherNet/IP using CX-
One
--- --- --- ---
OK
---
OK OK
Online connection via
EtherNet/IP using Net-
work Configurator
OK OK OK OK
---
OK OK OK
Mounting in an NJ-
series CPU Unit
--- --- --- --- --- --- ---
OK
*2
Connection settings
using the Sysmac Stu-
dio
OK OK OK OK
--- --- ---
OK
*1. This is equivalent to the event log in the built-in EtherNet/IP of an NJ-series Controller.
*2. You cannot use the following functions if you connect to the CPU Unit through an EtherNet/IP Unit.
• Placing the Sysmac Studio online with the CPU Unit (However
, you can place the Network Configurator online)
• Using the Troubleshooter of an NS-series PT
Appendices
A-2
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
