Settings not required.
Setting only with the Network
Configurator is possible.
Setting with the Sysmac
Studio is possible.
Tag and tag set settings
Tag and tag set settings
Tag and tag set settings
CS-/CJ-series PLC
FH/FZ/FQ/ZW-series Sensor
or another similar unit
(CPU Unit built-in EtherNet/IP port
or EtherNet/IP Unit)
Tag and tag set settings Connection settings
Setting with the Sysmac
Studio is possible.
Setting with the Sysmac
Studio is possible.
Settings for the target device
Settings for the originator device
NJ-series Controller NJ-series Controller
(CPU Unit built-in
EtherNet/IP port or
EtherNet/IP Unit)
NX-series Controller NX-series Controller
(Two built-in
EtherNet/IP ports)
(Two built-in
EtherNet/IP ports)
Use the Network Configurator if a CS/CJ-series PLC operates as the originator device.
NJ/NX-series ControllerCS-/CJ-series PLC
Settings for the target device
Settings for the originator device
Setting only with
the Network Configurator is possible.
A-2-2
Procedure to Make the EtherNet/IP Connection Settings with the
Sysmac Studio
1 Registering devices
• Main Window
↓ Register devices with which the EtherNet/IP connections
are established to the project.
Setup Window
2 Creating network variables
*1
--- Refer to Registering the Net-
work V
ariable for the Origina-
tor Device on page A-10.
Global Variable Table on the
Sysmac Studio
↓
3 Registering tags and tag sets --- Refer to Registering the T
ag
and Tag Set on page A-11.
EtherNet/IP Connection Set-
tings (Tag Set Display)
Appendices
A-4
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
