3 Specifications
3-2
G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
3-1 Servo Drive Specifications
Select a Servo Drive that matches the Servomotor to be used. Refer to 2-3-3 Servo Drive and
Servomotor Combination Tables on page 2-14.
Note 1 The above items reflect individual evaluation testing. The results may differ under compound conditions.
2 Never perform dielectric strength or other megameter tests on the Servo Drive. Failure to follow this guideline may
result in damaging the internal elements.
3 Some Servo Drive parts will require maintenance. For details, refer to 12-5 Periodic Maintenance on page 12-36.
3-1-1 General Specifications
Item Specifications
Ambient operating temperature and
operating humidity
0 to 55°C, 90% max. (with no condensation)
Storage ambient temperature and
humidity
−20 to 65°C, 90% max. (with no condensation)
Operating and storage atmosphere No corrosive gases
Vibration resistance
10 to 60 Hz and at an acceleration of 5.88 m/s
2
or less (Not to be run continuously at
a resonance point)
Insulation resistance Between power supply terminals/power terminals and FG terminal: 0.5 MΩ min. (at
500 VDC)
Dielectric strength Between power supply/power line terminals and FG terminal: 1,500 VAC for 1 min at
50/60 Hz
Protective structure Built into panel
EC Directives EMC Directive EN 55011, EN 61000-6-2, IEC 61800-3
Low Voltage
Directive
EN 61800-5-1
Machinery
Directive
EN954-1 (Category 3), EN ISO 13849-1: 2008 (Category 3) (PLc,d), ISO 13849-1:
2006 (Category 3) (PLc,d), EN61508 (SIL2), EN62061 (SIL2), EN61800-5-2 (STO),
IEC61326-3-1 (SIL2)
UL standards UL 508C
CSA standards CSA22.2 No. 14
Korean Radio Regulations (KC) Compliant
International standard
To Next Page
