4-21
4 System Design
G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
4-2 Wiring
4
4-2-3 Main Circuit and Motor Connections
When wiring the main circuit, use proper wire sizes, grounding systems, and noise resistance.
z Main Circuit Connector Specifications (CNA)
z Motor Connector Specifications (CNB)
4-2-3 Main Circuit and Motor Connections
R88D-KNA5L-ECT/-KN01L-ECT/-KN02L-ECT/-KN04L-ECT/
R88D-KN01H-ECT/-KN02H-ECT/-KN04H-ECT/-KN08H-ECT/
R88-KN10H-ECT/-KN15H-ECT
Symbol Name Function
L1 Main circuit power supply
input
R88D-KNL-ECT
50 to 400 W : Single-phase 100 to 120 VAC (85 to 132 VAC) 50/60 Hz
R88D-KNH-ECT
100 W to 1.5 kW :
Single-phase 200 to 240 VAC (170 to 264 VAC) 50/60 Hz
100 W to 1.5 kW : 3-phase 200 to 240 VAC (170 to 264 VAC) 50/60 Hz
L2
L3
L1C Control circuit power
supply input
R88D-KNL-ECT :
Single-phase 100 to 120 VAC (85 to 132 VAC) 50/60Hz
R88D-KNH-ECT :
Single-phase 200 to 240 VAC (170 to 264 VAC) 50/60 Hz
L2C
Symbol Name Function
B1 External Regeneration
Resistor connection
terminals
50 to 400 W: Normally, do not short B1 and B2. Doing so may result in
malfunctioning. If there is high regenerative energy, connect an External
Regeneration Resistor between B1 and B2.
750 W to 1.5 kW: Normally B2 and B3 are shorted. Do not short B1 and
B2. Doing so may result in malfunctioning. If there is high regenerative
energy, remove the short bar between B2 and B3 and connect an External
Regeneration Resistor between B1 and B2.
B3
B2
U Motor connection
terminals
Red These are the output terminals to the Servomotor.
Be sure to wire them correctly.
VWhite
WBlue
Green/
Ye l l o w
Frame ground This is the ground terminal. Ground to 100 Ω or less.
