3 Specifications
3-8
G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
When wiring the main circuit, use proper wire sizes, grounding systems, and noise resistance.
z Main Circuit Connector Specifications (CNA)
z Motor Connector Specifications (CNB)
3-1-4 Main Circuit and Motor Connections
R88D-KNA5L-ECT/-KN01L-ECT/-KN02L-ECT/-KN04L-ECT/
-KN01H-ECT/-KN02H-ECT/-KN04H-ECT/-KN08H-ECT/
-KN10H-ECT/-KN15H-ECT
Symbol Name Function
L1 Main circuit power
supply input
R88D-KNL-ECT
50 to 400 W: Single-phase 100 to 120 VAC (85 to 132 V) 50/60 Hz
R88D-KNH-ECT
100 W to 1.5 kW: Single-phase: 200 to 240 VAC (170 to 264 V) 50/60 Hz
100 W to 1.5 kW: 3-phase: 200 to 240 VAC (170 to 264 V) 50/60 Hz
Note: Single-phase should connect to L1 and L3.
L2
L3
L1C Control circuit power
supply input
R88D-KNL-ECT: Single-phase 100 to 120 VAC (85 to 132 V) 50/60 Hz
R88D-KNH-ECT : Single-phase 200 to 240 VAC (170 to 264 V) 50/60 Hz
L2C
Symbol Name Function
B1 External Regeneration
Resistor connection
terminals
50 to 400 W: Normally, do not short B1 and B2. Doing so may result in
malfunctioning. If there is high regenerative energy, connect an External
Regeneration Resistor between B1 and B2.
750 W to 1.5 kW: Normally B2 and B3 are shorted. Do not short B1 and B2.
Doing so may result in malfunctioning. If there is high regenerative energy,
remove the short-circuit bar between B2 and B3 and connect an External
Regeneration Resistor between B1 and B2.
B3
B2
U Motor connection
terminals
Phase U These are the output terminals to the Servomotor.
Be sure to wire them correctly.
V Phase V
W Phase W
