2 Models and External Dimensions
2-28
G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
2-4 External and Mounting Dimensions
This section describes the external dimensions and the mounting dimensions of Servo Drives,
Servomotors, and peripheral devices.
The dimensional description starts with a Servo Drive of the smallest motor capacity, which is followed
by the next smallest, and so on.
z Wall Mounting
External dimensions Mounting dimensions
2-4-1 Servo Drive Dimensions
Single-phase 100 VAC: R88D-KNA5L-ECT/-KN01L-ECT (50 to 100 W)
Single-phase/3-phase 200 VAC: R88D-KN01H-ECT/-KN02H-ECT
(100 to 200 W)
13270
40
150
40
28
6
150 140
2-M4
