9-3 Vibration Suppression Settings
• Set the operation of the adaptive filter.
• Refer to 11-6 Adaptive Filter on page 11-20.
Explanation of Set Values
• Set the frequency of resonance suppression notch filter 1.
• The notch filter function is disabled if this object is set to 5000.
• Refer to 11-7 Notch Filters on page 11-23.
• Set the width of resonance suppression notch filter 1 to one of 20 levels.
• Increasing the setting value widens the notch width. Normally, use the default set value.
• Refer to 11-7 Notch Filters on page 11-23.
• Set the notch depth of resonance suppression notch filter 1.
• Increasing the setting value shortens the notch depth and the phase lag.
• Refer to 11-7 Notch Filters on page 11-23.
3200 hex
Adaptive Filter Selection
Setting range 0 to 4 Unit −
Default setting
0 Data attribute B
Size 2 bytes (INT16) Access RW PDO map Not possible.
Set value Description
0 Adaptive filter disabled
1 One adaptive filter is enabled. The objects related to notch filter 3 are automatically updated.
2 Two adaptive filters are enabled. The objects related to notch filters 3 and 4 are updated.
3 For use by manufacturer. Do not use this setting.
4 Adaptive result is cleared. Objects related to notch filters 3 and 4 are disabled and the adaptive
result is cleared.
3201 hex
Notch 1 Frequency Setting
Setting range 50 to 5000 Unit Hz
Default setting
5000 Data attribute B
Size 2 bytes (INT16) Access RW PDO map Not possible.
3202 hex
Notch 1 Width Setting
Setting range 0 to 20 Unit −
Default setting
2 Data attribute B
Size 2 bytes (INT16) Access RW PDO map Not possible.
3203 hex
Notch 1 Depth Setting
Setting range 0 to 99 Unit −
Default setting
0 Data attribute B
Size 2 bytes (INT16) Access RW PDO map Not possible.
