9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
3.5
GENERAL INFORMATION
SERVICE SPECIFICATIONS
ENGINE
DESCRIPTION SPECIFICATION
Cylinder Head Warp Limit 0.006 in (.015 mm)
Cylinder Taper Limit 0.002 in (0.051 mm)
Cylinder Out-of-Round
Limit
0.002 in (0.051 mm)
Piston Measuring Point 0.98 in (25 mm)
Piston to Cylinder Service
Limit
0.0079 in (.200 mm)
Reed Valve Air Gap 0.015 in (.381 mm)
Connecting Rod Side
Clearance
0.030 in (0.762 mm)
Crankshaft Runout Limit
0.0025 in (0.030 mm)
IMPORTANT ENGINE SERVICE NOTES
The Oil Pump Enrichment Mode Timer MUST be reset
using Digital Wrench whenever the following engine
service actions are completed:
• Engine rebuild
• New cylinder installed
• New pistons / rings installed
• New crankcase installed
• New crankshaft / crank bearings installed
• New water pump cross shaft installed
To reset the Oil Pump Enrichment Mode Timer, see Oil
Pump Enrichment Mode Timer Reset page 1.57.
BREAK-IN
FUNCTION
ENGINE RUN
TIME
DURATION
DESCRIPTION
Fuel Injectors
2 hours *
2% additional
fuel
Oil Pump
Enrichment
Period
10 Hours *
15% additional
enriched oil
supply to engine
* = Total engine run time above 3,500 RPM
The Electronic Oil Pump Prime procedure MUST be
performed using Digital Wrench whenever the following
engine service actions are completed and the engine has
been reinstalled back into the chassis:
• Engine rebuild
• New cylinder installed
• New pistons / rings installed
• New crankcase installed
• New crankshaft / crank bearings installed
• New water pump cross shaft installed
• Oil supply hoses to engine have 1 inch (2.54 cm) or
larger air bubbles
• Oil pump is replaced
NOTICE
Perform the Electronic Oil Pump Prime procedure until
ALL of the air is purged from the lines and then prime at
least two additional times to push oil into bearings.
To perform the Electronic Oil Pump Prime procedure, see
Electronic Oil Pump Prime Procedure page 1.64.
ENGINE / COOLING / EXHAUST
