DIAGNOSTIC TROUBLE CODES (DTCS) - LEFT HAND CONTROL
SPN = SUSPECT PARAMETER NUMBER / FMI = FAILURE MODE INDICATOR
SPN FMI
P-
CODE
DESCRIPTION WHAT CAUSES IT LHC RESPONSE
PRIMARY
COURSE OF
ACTION
SECONDARY
COURSE OF
ACTION
FAULT CLEAR
516360
0 C1106
Left Grip Heater
Driver Over Temp
Left grip heater
measured current
exceeds current limit
value
Disable left grip
heater,
periodically
measure current
at low duty cycle
Check left grip
heater for a short
circuit to the
handlebars
Check left grip
heater wiring for
a short circuit
near console
Left grip heater
current falls
below (current
limit - hystersis)
5 C1107
Left Grip Heater
Driver Under
Current
Left grip heater
measured current
below current limit
value
Continue normal
operation
Check left grip
heater for
damage or an
open circuit
Check left grip
heater wiring for
broken wire near
console
Left grip heater
current rises
above (current
limit + hystersis)
6 C1108
Left Grip Heater
Driver Over
Current
Left grip heater
measured
temperature exceeds
temperature limit
value
Disable left grip
heater
Remove vehicle
from hot location
or direct sunlight
Check left grip
heater for
damage, replace
left hand control
Left grip heater
temperature falls
below
(temperature limit
- hystersis)
31 C1109
Left Grip Heater
Driver Internal
Short
Left grip heater driver
FET shorted
Disable left grip
heater
Replace left hand
control
Shorted FET
condition does
not exist
516361
0 C110A
Right Grip Heater
Driver Over Temp
Right grip heater
measured current
exceeds current limit
value
Disable right grip
heater,
periodically
measure current
at low duty cycle
Check right grip
heater for a short
circuit to the
handlebars
Check right grip
heater wiring for
a short circuit
near console
Right grip heater
current falls
below (current
limit - hystersis)
5 C110B
Right Grip Heater
Driver Under
Current
Right grip heater
measured current
below current limit
value
Continue normal
operation
Check right grip
heater for
damage or an
open circuit
Check right grip
heater wiring for
broken wire near
console
Right grip heater
current rises
above (current
limit + hystersis)
6 C110C
Right Grip Heater
Driver Over
Current
Right grip heater
measured
temperature exceeds
temperature limit
value
Disable right grip
heater
Remove vehicle
from hot location
or direct sunlight
Check right grip
heater for
damage, replace
left hand control
Right grip heater
temperature falls
below
(temperature limit
- hystersis)
31 C110D
Right Grip Heater
Driver Internal
Short
Right grip heater
driver FET shorted
Disable right grip
heater
Replace left hand
control
Shorted FET
condition does
not exist
516362
0 C110E
Thumb Heater
Driver Over Temp
Thumb heater
measured current
exceeds current limit
value
Disable thumb
heater,
periodically
measure current
at low duty cycle
Check thumb
heater for a short
circuit to the
handlebars
Check thumb
heater wiring for
a short circuit
near console
Thumb heater
current falls
below (current
limit - hystersis)
5 C110F
Thumb Heater
Driver Under
Current
Thumb heater
measured current
below current limit
value
Continue normal
operation
Check thumb
heater for
damage or an
open circuit
Check thumb
heater wiring for
broken wire near
console
Thumb heater
current rises
above (current
limit + hystersis)
6 C1110
Thumb Heater
Driver Over
Current
Thumb heater
measured
temperature exceeds
temperature limit
value
Disable thumb
heater
Remove vehicle
from hot location
or direct sunlight
Check thumb
heater for
damage, replace
left hand control
Thumb heater
temperature falls
below
(temperature limit
- hystersis)
31 C1111
Thumb Heater
Driver Internal
Short
Thumb heater driver
FET shorted
Disable thumb
heater
Replace left hand
control
Shorted FET
condition does
not exist
