9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
LOWER STEERING ASSEMBLY VIEW
q
Steering Post
a
Washer
1(
Rack Link
w
Lower Steering Post Bushing
s
Washers
2)
Fixed Drag Link
e
Bushing Spacers
d
Nut
37 ft-lbs (50 N·m)
2!
Fixed Drag Link to Pitman Arm
Fastener
20 ft-lbs (27 N·m)
r
Washer
f
Rod End
2@
Pitman / Idler Arm to Bracket
Fasteners
30 ft-lbs (41 N·m)
t
Nut
44 ft-lbs (60 N·m)
g
Nut
11 ft-lbs (15 N·m)
2#
Pivot Shaft
y
Steering Strap
h
Tie Rod
2$
Pivot Bushing
u
Lower Steering Post Bushing
Mount Fasteners
20 ft-lbs (27 N·m)
j
Nut
11 ft-lbs (15 N·m)
2%
Nut
i
Nut
37 ft-lbs (50 N·m)
k
Rod End
2^
Idler Arm
o
Nut
20 ft-lbs (27 N·m)
l
Rack Link to Pitman / Idler Arm
Fasteners
2&
Pitman Arm
STEERING / SUSPENSIONS
