9
9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
9.17
CONSOLE ASSEMBLY VIEW
q
Console
d
Ignition Switch
w
Console Fasteners
71 in-lbs (8 N·m)
f
Retainer
e
Belt Removal Tool
g
RH Console Trim
r
LH Lower Console Foam
h
Console Vent
t
Seal
j
Recoil Handle
y
LH Console Trim
k
Recoil Pocket
u
LH Upper Console Foam
l
Recoil Roller Nut
71 in-lbs (8 N·m)
i
Filler Neck Nut
1(
Roller Bushing
o
1/4 Turn Clip
2)
Recoil Roller
a
Plastic Rivets
2!
Recoil Roller Fastener
s
Console Switch Panel
CHASSIS
