R&S OSP Instrument Functions
Operating Manual 1505.3896.12 - 14 129
5.5 R&S OSP Selftest
The R&S OSP provides a basic selftest procedure on module level. The selftest is
primarily intended for production and service purposes; it is not needed during normal
operation of the instrument. The following description serves as a general overview.
5.5.1 Selftest via R&S OSP Panel
A selftest can be performed for the R&S OSP via the OSP Panel. See chapter 3 for
information on the installation and operation of the OSP Panel application.
The selftest result reflects the current instrument status and checks if all the hardware
as shown in OSP Panel module catalog is correctly initialized.
The selftest does not execute special hardware tests.
The selftest is started as follows:
► Select >Utility >Self Test … in the OSP Panel.
The selftest is started immediately and with positive result, the following message will
appear:
Press OK to exit the Selftest Utility.
5.6 R&S OSP Configuration Check
The R&S OSP and the installed modules all are equipped with on-board memory
containing the actual device and module data. These data are primarily intended for
production and service purposes.
5.6.1 System Info via R&S OSP Panel
The system information can be read out of the R&S OSP via the OSP Panel. See
chapter 3 for information on the installation and operation of the OSP Panel
application.
The system info can be read as follows:
► Select >File >System Info … in the OSP Panel.
The system information is read from the R&S OSP hardware and the following text file
is opened and displayed:
