Optional Equipment
Paper Feed Unit (D573)
Paper Feed System: Feed Roller and Friction Pad
Paper Height Detection: Empty only
Tray Capacity: 500 sheets
Paper Weight: 60 to 163 g/m
2
(16 to 43.5 lb.)
Paper Size: A5 SEF to A4/LG SEF
Power Source: DC 24V, 5V (from the main frame)
Power Consumption:
Less than 27 W
(Power is supplied from the main unit.)
Dimensions (W x D x H): 498 mm x 552 mm x 150 mm (19.7" x 21.8" x 6.0")
Weight: 10.4 kg (23.0 lb.) or less
1-bin Tray Unit (D574)
Paper detection: Detects paper
Tray Capacity: 100 sheets (80 g/m
2
)
Paper Weight: 60 to 163 g/m
2
(16 to 43.5 lb.)
Paper Size:
Width: 139.7 to 216mm (5.0” to 8.5”)
Length: 210 to 600mm (8.3” to 23.7”)
Power Source: DC 24V, 5V (from the main frame)
Power Consumption:
Less than 1 W
(Power is supplied from the main unit.)
Dimensions (W x D x H): 540 mm x 460 mm x 116 mm (21.3" x 18.1" x 4.6")
Weight: 3.0 kg (6.6 lb.) or less
Optional Equipment
13
