Main SP Tables-2
SP2-XXX (Drum)
2102
[Magnification Adjustment]
These values are the parameters for the automatic line position adjustment and are
adjusted at the factory. These SPs must be input only when a new laser unit is installed.
001 Main Mag.: High Speed: Bk *ENG
[-1.000 to 1.000 / 0.000 / 0.001/step]
004 Main Mag.: High Speed: Ma *ENG
007 Main Mag.: High Speed: Cy *ENG
010 Main Mag.: High Speed: Ye *ENG
028
Color Main Mag.: High Speed:
Ma
*ENG
[-1.000 to 1.000 / 0.000 / 0.001/step]031
Color Main Mag.: High Speed:
Cy
*ENG
034
Color Main Mag.: High Speed:
Ye
*ENG
2103
[Erase Margin Adjustment] (Area, Paper Size)
Adjusts the erase margin by deleting image data at the margins.
001 Lead Edge Width *ENG
[0.0 to 9.9 / 4.2 / 0.1mm/step]
002 Trail. Edge Width *ENG
003 Left *ENG
[0.0 to 9.9 / 2.0 / 0.1mm/step]
004 Right *ENG
005 Duplex Trail *ENG
[0.0 to 9.9 / 0.0 / 0.1mm/step]006 Duplex Left Edge *ENG
007 Duplex Right Edge *ENG
Main SP Tables-2
351
