No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
The feedback voltage of the charge AC for each color is 0.3 V or less for 0.2
seconds after the charge AC has turned on.
• Disconnected or broken harnesses of the HVPS
•
Defective PCDU
•
Defective HVPS
1. Check or replace the harnesses of the HVPS.
2. Reinstall or replace the PCDU.
3. Replace the HVPS.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
325 D
Color development motor error
The motor LOCK signal is not detected for more than two seconds while the motor
START signal is on.
• Color development motor slip due to an increase in the torque caused by
connected components
• Defective motor
1. Adjust the torque properly by replacing or cleaning the PCDU.
2. Replace the PCDU.
3. Replace the development motor: CMY if load torque is normal.
SC3xx: Image Processing – 2
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
360
-01
D
TD sensor (Vt high) error 1: Bk
The Vt value of the black TD sensor exceeds the specified value (SP3030-031)
0.2 V for three consecutive times.
-02 D
TD sensor (Vt high) error 1: Cy
The Vt value of the cyan TD sensor exceeds the specified value (SP3030-032)
0.2 V for three consecutive times.
SC Tables
645
