Ricoh AFICIO MP C305SP Field Service Manual

Image Adjustment
Scanning
Check the printing registration/side-to-side adjustment and the blank margin adjustment before you do
the following scanner adjustments.
• Use C-4 test chart to do the following adjustments.
Scanner sub-scan magnification
A: Sub-scan magnification
1. Put the test chart on the exposure glass. Then make a copy from one of the feed stations.
2. Check the magnification ratio. Adjust with SP4-008 if necessary.
Standard: ±1.0%.
Image Adjustment
159
