Main SP Tables-9
Input Check Table
When entering the Input Check mode, 8 digits display the result for a section. Each digit corresponds to
a different device as shown in the table.
Bit No. 7 6 5 4 3 2 1 0
Result 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1
Copier
5803 Description
Reading
0 1
5803-001 Regist Sensor Paper detected Paper not detected
5803-002 Tray Paper End Sensor Paper detected Paper not detected
5803-003 Bypass Paper End Sensor Paper detected Paper not detected
5803-004 Bypass Paper Width Detection Paper detected Paper not detected
5803-005 Tray Lift Motor Position Sensor (Not used)
5803-006 Duplex Exit Sensor Paper detected Paper not detected
5803-007 Exit Sensor Paper detected Paper not detected
5803-008 Duplex Entrance Sensor Paper detected Paper not detected
5803-009 Tray Full Exit Sensor (Not used)
5803-010 Bypass Lift Positon Up Down
5803-011 Tray Exit Sensor Paper detected Paper not detected
5803-012 Interlock Release Detection 1 Door open Door close
5803-013 Interlock Release Detection 2 Door open Door close
5803-014 Right Cover Sensor Door close Door open
5803-015 +24V_DCTH Detection (Not used)
5. System Maintenance
580
