Optional Equipment
Paper Feed Unit (D573)
Paper Feed System: FRR
Paper Height Detection: Empty only
Capacity: 500 sheets
Paper Weight: 60 to 163 g/m
2
(16 to 43.5 lb.)
Paper Size: A5/HLT to A4/LG SEF
Power Source: DC 24V, 5V (from the main frame)
Power Consumption: Less than 27 W
Dimensions (W x D x H): 498 mm x 552 mm x 150 mm (19.6" x 21.7" x 5.9")
Weight: 10.4 kg (22.1 lb.) or less
1-bin Tray Unit (D574)
Paper Size: A5/HLT to A4/LG SEF
Paper Weight: 60 to 163 g/m
2
, 16 to 43.5 lb.
Tray Capacity: 100 sheets (80 g/m
2
)
Power Source: DC 24V, 5V (from the main frame)
Power Consumption: Less than 1 W
Weight: 3.0 kg (6.6 lb.) or less
Dimensions (W x D x H): 540 mm x 460 mm x 116 mm (21.3" x 18.1" x 4.6")
Utility Software
Software Description
Font Manager 2000 A font management utility with screen fonts for the printer
1. Appendices
10
