Page #303 background imageLoading...
Page #303 background image
2. BICU [A] ( x 7, all s)
• The EPPROM [B] on the old BICU board should be transferred to the new BICU board. Insert
the NVRAM with the notch on the EPPROM pointing downward.
PSU
1. Controller box ( p.295)
Electrical Components
301
