Electrical Components
Controller Box
If the optional counter interface unit is installed, remove it before you remove the controller box.
1. Open the duplex unit.
2. Rear right cover ( p.178)
3. Rear cover ( p.177)
4. Left cover ( p.175)
5. Scanner rear cover ( p.186 "Scanner Unit")
6. Exhaust fan ( p.313)
Electrical Components
295
