2. Original feed unit [A]
Pick-up Roller
1. Original feed unit ( p.317)
2. Release the hook [A].
3. Slide the shaft [A], and then remove the pick-up roller [B].
Feed Roller
1. Original feed unit ( p.317)
4. Replacement and Adjustment
318
