4. Select "Printer SP".
5. Select SP1-102-001. Then select the necessary print mode to adjust.
6.
Choose SP1-103-1 to print out a tone control test sheet if you want to examine the image quality
for these settings.
7. Adjust the color density with SP1-104. Compare the tone control test sheet with the C4 test chart.
• Adjust the density in this order: "ID Max", "Shadow", "Middle", "Highlight".
8. Use SP1-105-001 to keep the adjusted settings.
Color Skew Adjustment
The skew adjustment of this machine should be performed manually. The adjustment flow is as follows:
1. Execute ‘MUSIC’ (SP2-111-002) and check the result for each color with the following SPs.
•
SP2-117-004 (Black)
• SP2-117-002 (Cyan)
• SP2-117-001 (Magenta)
• SP2-117-003 (Yellow)
2. The color skew adjustment should be executed if one or more of the above SP values is not within
±5. No skew adjustment is required when all SP values are within ±5. However, if one or more of
the SP values is not within ±5, then you must adjust color skew for any color that has an SP value
that is not 0.
Image Adjustment
169
