Main SP Tables-4
SP4-XXX (Scanner)
4008
[Sub Scan Mag.Adjustment]
Adjusts the sub-scan magnification by changing the scanner motor speed.
001 - *ENG [-1.0 to 1.0 / 0.0 / 0.1%/step]
4010
[L-Edge Regist Adjustment]
Adjusts the leading edge registration by changing the scanning start timing in the sub-scan
direction.
001 - *ENG [-1.0 to 1.0 / 0.0 / 0.1mm/step]
4011
[S-to-S Regist Adjustment]
Adjusts the side-to-side registration by changing the scanning start timing in the main scan
direction.
001 - *ENG [-2.0 to 2.0 / 0.0 / 0.1mm/step]
4012
[Scanner Erase Margin: Scale]
Sets the blank margin at each side for erasing the original shadow caused by the gap
between the original and the scale.
001 Book: Leading Edge *ENG [0.0 to 3.0 / 0.0 / 0.1mm/step]
002 Book: Trailing Edge *ENG [0.0 to 3.0 / 0.0 / 0.1mm/step]
003 Book: Left *ENG [0.0 to 3.0 / 0.0 / 0.1mm/step]
004 Book: Right *ENG [0.0 to 3.0 / 0.0 / 0.1mm/step]
4013
[Scanner Free Run]
Performs the scanner free run with the exposure lamp on or off in the following mode.
Full color mode / Full Size / A3 or DLT
001 Lamp OFF ENG [0 or 1 / 0 / 1/step] 0:OFF, 1:ON
Main SP Tables-4
425
