• Never re-use a thermostat that has activated. Use a new thermostat for replacement.
Fusing Thermistor
1. Fusing upper cover ( p.245)
2. Remove the fusing thermistor with the bracket [A], and then remove the fusing thermistor from the
bracket ( x1, x 2)
Fusing Pressure Roller Thermistors
1. Fusing upper cover ( p.245)
Fusing
247
