Logical Page and Object Area Coloring
Color Specification
The Color Specification triplet is used to specify the foreground color of the logical page or object area
before any object data is placed on the logical page or object area.
Offset Range Meaning Error Code
0 X'0E'-X'10' TRIPLET LENGTH X'020E..01'
1 X'4E' COLOR
SPECIFICATION
TRIPLET
2 X'00' RESERVED
3 COLOR SPACE (Note
1)
X'020E..02'
X'01' RGB - Limited
Simulated Color
Support
X'04' CMYK - Limited
Simulated Color
Support
X'06' Highlight - Limited
Simulated Color
Support
X'08' CIELAB - Limited
Simulated Color
Support
X'40' Standard OCA -
Limited Simulated
Color Support
4-7 X'00000000' RESERVED
Color Simulation
33
