5. Graphics Command Set
Graphics Commands
The base reference for graphic drawing orders is the Graphics Object Content Architecture Reference.
Name Command Sub-command Where to Look
Write Graphics Control X'D684' p.161 "Write
Graphics Control"
Graphics Area Position X'AC6B' p.161 "Graphics Area
Position"
Graphics Output
Control
X'A66B' p.162 "Graphics
Output Control"
Graphics Data
Descriptor
X'A6BB' p.164 "Graphics Data
Descriptor"
Write Graphics X'D685' p.169 "Write
Graphics"
Begin Segment
Introducer
X'70' p.170 "Begin Segment
Introducer"
Write Graphics Control
Graphics Area Position
Offset Range Meaning Error Code
0-1 X'000B'-
X'xxxx'
LENGTH of Graphics Area Position X'0202..0
5'
2-3 X'AC6B' Structured Field ID. X'020B..
05'
4-5 X'8000'-
X'7FFF'
GRAPHICS BLOCK ORIGIN Xp, I, or I-offset Coordinate
Position.
See "Notation Conventions", IPDS Technical Reference 1.
161
