249
a) See page 245.
b) 0 is a round shape, and 100 is the shape of the pattern. Smaller values
make the pattern more rounded.
c) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction.
To rotate the shape pattern
1
In the Light 1 menu (4156.3), press [Shape Speed],
turning it on.
When [Shape] is selected, the display of the 5th
parameter changes.
2
Set the following parameters.
a) –100.00 is four rotations per second in the counterclockwise
direction, and +100.00 is four rotations per second in the clockwise
direction. 0.00 stops the rotation.
To change the light to a ring shape
When [Parallel] or [Whole] is selected in the <Spot Mode>
group, the Ring parameter cannot be set if Shape is
disabled.
1
In the Light 1 menu (4156.3), press [Ring].
2
Set the following parameters.
a) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction.
There is no [Radius] parameter setting when [Line] is
selected in the <Spot Mode> group.
To rotate the ring
1
In the Light 1 menu (4156.3), press [Ring Speed],
turning it on.
When [Ring] is selected, the display of the 3rd
parameter changes.
2
Set the following parameter.
a) –100.00 is four rotations per second in the counterclockwise
direction, and +100.00 is four rotations per second in the clockwise
direction. 0.00 stops the rotation.
To invert the illuminated area
In the Light 1 menu (4156.3), press [Light Invert], turning
it on.
To add color to the light source
1
In the Light 1 menu (4156.3), press [Light Color
Adjust].
The Light Color Adjust menu (4156.4) appears.
2
In the <Fill Blending Mode> group, select how the
light and image should be blended.
Mix: Lighting as if reflected from a mirror.
Multiply: Light as if reflected from a dull surface
(diffuse reflection).
3
When [Mix] is selected, select the fill color in the <Fill
Source> group.
Flat Color: A single color matte
Hue Rotation: Color matte with a color that gradually
varies
4
Set the following parameters, according to the fill
color selection.
When [Flat Color] is selected
When [Hue Rotation] is selected
2 Size Shape size
3 Deform Amount of shape deformation
b)
4 Soft Softness of shape pattern
5 Angle Angle of shape pattern rotation
c)
No. Parameter Adjustment
5 Speed Rotation speed and direction
a)
Note
No. Parameter Adjustment
1 Offset Offset from center position (radius)
2 Radius Radius of ring
3 Angle Rotation angle of ring
a)
Note
No. Parameter Adjustment
No. Parameter Adjustment
3 Speed Rotation speed and direction
a)
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
4 Brilliancy Brilliance of surface struck by light
a)
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
