Suzuki AN400 Service Manual

Rear Suspension: 2C-2
Rear Suspension Assembly Construction
B705H12306013
“a”
“a”
“a”
“a”
“a”
“a”
(a)
1
(a)
2
(a)
4
(a)
5
(b)
3
2
1
3
5
4
“A”
FWD
I705H1230041-04
1. Rear shock absorber mounting bolt 5. Cushion rod mounting nut : 80 N⋅m (8.0 kgf-m, 58.0 lb-ft)
2. Cushion lever nut “A”: Assemble the rear shock absorber with dent side up. : Apply grease.
3. Cushion lever mounting nut “a”: 1 mm (0.04 in)
4. Cushion rod nut : 50 N⋅m (5.0 kgf-m, 36.0 lb-ft)
