Suzuki AN400 Service Manual

1A-15 Engine General Information and Diagnosis:
Use of SDS Diagnosis Reset Procedures
B705H11104031
Clear the Past DTC using SDS in the following
procedures:
1) Set up the SDS tools.
2) After repairing the trouble, turn OFF the ignition
switch and turn ON again.
3) Click the DTC inspection button (1).
4) Check the DTC.
5) The previous malfunction history code (Past DTC)
still remains stored in the ECM. Therefore, erase the
history code memorized in the ECM using SDS tool.
NOTE
The malfunction code is memorized in the
ECM also when the wire coupler of any
sensor is disconnected. Therefore, when a
wire coupler has been disconnected at the
time of diagnosis, erase the stored
malfunction history code using SDS.
6) Click “Clear” (2) to delete history code (Past DTC).
7) Follow the displayed instructions.
8) Check that both “Current DTC” (3) and “Past DTC”
(4) are deleted (NIL).
1
I705H1110003-01
2
I705H1110005-01
I705H1110006-01
I705H1110009-01
3
4
I705H1110008-01

Suzuki AN400 Specifications

General

Fuel System	Fuel injection
Starter	Electric
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Engine Type	4-stroke, liquid-cooled, single-cylinder, DOHC
Bore x Stroke	81.0mm x 77.6mm
Front Brakes	Disc brake
Rear Brakes	Disc brake
Rear Tire	150/70-13M/C 64S, tubeless
