CLUTCH
L3301, L3901, L4701, WSM
2-S3
2. SERVICING SPECIFICATIONS
9Y1211012CLS0002US0
Item Factory Specification Allowable Limit
Clutch Pedal Free Travel 20 to 30 mm
0.8 to 1.2 in.
–
Pressure Plate to Adjusting Bolt Clearance 0.9 to 1.0 mm
0.035 to 0.039 in.
–
Clutch Disc Boss to Main Shaft (Travelling) Backlash
(Displacement
Around Disc Edge)
– 2.0 mm
0.079 in.
Clutch Disc Disc Surface to
Rivet Top (Depth)
– 0.3 mm
0.01 in.
Diaphragm Spring Mutual Difference – 0.5 mm
0.02 in.
Pressure Plate to Straightedge Clearance – 0.2 mm
0.008 in.
Belleville Spring Free Height 7.24 mm
0.285 in.
6.76 mm
0.266 in
Release Lever Mutual Difference 0 to 0.2 mm
0 to 0.008 in.
–
Gauge Ring to Adjusting Screw Clearance 0 to 0.7 mm
0 to 0.003 in.
–
Pressure Plate 2 to Adjusting Screw Clearance 0.90 to 1.0 mm
0.036 to 0.039 in.
–
KiSC issued 09, 2016 A
