FRONT AXLE
L3301, L3901, L4701, WSM
6-S2
2. SERVICING SPECIFICATIONS
[2WD]
Item Factory Specification Allowable Limit
Toe-in 2 to 8 mm
0.08 to 0.31 in.
–
Front Wheel Axial Sway Less than
5.0 mm
0.20 in.
–
Front Axle Rocking Force 49 to 196 N·m
5.0 to 20.0 kgf·m
11 to 44 lbf·ft
–
Front Axle Middle Boss to Front Axle Shaft
Bracket Bushing
• Front Axle Middle Boss
• Bushing
Clearance
O.D.
I.D.
0.015 to 0.177 mm
0.0006 to 0.00696 in.
39.938 to 40.000 mm
1.5724 to 1.5748 in.
40.015 to 40.115 mm
1.5754 to 1.5793 in.
0.3 mm
0.01 in.
–
–
Knuckle Shaft (Kingpin) to Bushing
• Knuckle Shaft
• Bushing
Clearance
(L3301/L3901)
Clearance
(L4701)
O.D.
(L3301/L3901)
O.D.
(L4701)
I.D.
(L3301/L3901)
I.D.
(L4701)
0 to 0.285 mm
0 to 0.0112 in.
0 to 190 mm
0 to 0.007482 in.
27.880 to 27.900 mm
1.0977 to 1.0984 in.
37.975 to 38.000 mm
1.4951 to 1.4960 in.
27.900 to 28.165 mm
1.0985 to 1.1088 in.
38.000 to 38.165 mm
1.4961 to 1.15025 in.
0.4 mm
0.02 in.
0.4 mm
0.02 in.
–
–
–
–
Steering Cylinder I.D. 55.000 to 55.074 mm
2.1654 to 2.1682 in.
55.100 mm
2.1693 in.
Rod to Bushing Clearance 0.00900 to 0.127 mm
0.000355 to 0.00500 in.
0.135 mm
0.00531 in.
KiSC issued 09, 2016 A
