ELECTRICAL SYSTEM
L3301, L3901, L4701, WSM
9-S32
[8] OPC (OPERATOR PRESENCE CONTROL) SYSTEM
(1) L3301/L3901
<Manual Transmission Model>
 Preparation before checking
1. Sit on operator's seat.
2. Set the parking brake.
3. Shift the main gear shift lever and the synchro shuttle shift lever to "NEUTRAL" position.
4. Shift the PTO gear shift lever to "OFF" position.
5. Fully depress the clutch pedal and start the engine.
6. Check the OPC system by following four steps listed in the table below.
IMPORTANT
• Be sure to set main gear shift lever to "NEUTRAL" position.
Checking System
9Y1211012ELS0047US0
<HST Model>
 Preparation before checking
1. Sit on operator's seat.
2. Set the parking brake.
3. Shift the range gear shift lever and release the HST pedal to "NEUTRAL" position.
4. Shift the PTO gear shift lever to "OFF" position.
5. Fully depress the clutch pedal and start the engine.
6. Check the OPC system by following four steps listed in the table below.
IMPORTANT
• Be sure to set range gear shift lever to "NEUTRAL" position.
Checking System
9Y1211012ELS0048US0
Step
PTO Gear
Shift Lever
Synchro Shuttle
Shift Lever
Operator
OPC System is
"NORMAL" If
1
"OFF"
(Switch: ON)
"FOWARD" or
"REVERSE"
(Switch: OFF)
Gets up from the seat
(Seat switch: OFF)
Engine stops
2
"ON"
(Switch: OFF)
"NEUTRAL"
(Switch: ON)
Gets up from the seat
(Seat switch: OFF)
Engine stops
3
"OFF"
(Switch: ON)
"NEUTRAL"
(Switch: ON)
Gets up from the seat
(Seat switch: OFF)
Engine does not stop
4
"OFF"
(Switch: ON)
"NEUTRAL"
(Switch: ON)
Gets off the tractor, tilts the
seat forward, and then
place PTO gear shift lever
to ON position
(Seat switch: ON)
Engine does not stop
Step
PTO Gear
Shift Lever
HST Pedal Operator
OPC System is
"NORMAL" If
1
"OFF"
(Switch: ON)
"FORWARD" or
"REVERSE"
(Switch: OFF)
Gets up from the seat
(Seat switch: OFF)
Engine stops
2
"ON"
(Switch: OFF)
"NEUTRAL"
(Switch: ON)
Gets up from the seat
(Seat switch: OFF)
Engine stops
3
"OFF"
(Switch: ON)
"NEUTRAL"
(Switch: ON)
Gets up from the seat
(Seat switch: OFF)
Engine does not stop
4
"OFF"
(Switch: ON)
"NEUTRAL"
(Switch: ON)
Gets off the tractor, tilts the
seat forward, and then
place PTO gear shift lever
to ON position
(Seat switch: ON)
Engine does not stop
