TRANSMISSION
L3301, L3901, L4701, WSM
3-S6
2. SERVICING SPECIFICATIONS
[1] L3301/L3901
Item Factory Specification Allowable Limit
Gear Backlash 0.1 to 0.3 mm
0.0040 to 0.011 in.
0.4 mm
0.02 in.
Gear to Spline Clearance 0.030 to 0.078 mm
0.0012 to 0.0030 in.
0.20 mm
0.008 in.
Shift Fork and Shift Gear Groove Clearance 0.15 to 0.40 mm
0.0059 to 0.015 in.
0.6 mm
0.02 in.
Shift Fork to Shifter Groove Clearance 0.15 to 0.40 mm
0.0059 to 0.015 in.
0.6 mm
0.02 in.
Shift Fork Spring Free Length 22.0 mm
0.87 in.
20.0 mm
0.79 in.
Differential Gear Rotating Torque 3.9 to 6.3 N·m
0.40 to 0.6 kgf·m
2.9 to 4.6 lbf·ft
–
Bevel Gear to 8T Spiral Bevel Pinion Backlash 0.15 to 0.30 mm
0.0059 to 0.011 in.
–
Differential Case Bore to Differential Side
Gear Boss
• Differential Case Bore
• Differential Side Gear Boss
Clearance
I.D.
O.D.
0.0500 to 0.151 mm
0.00197 to 0.00594 in.
40.500 to 40.562 mm
1.5945 to 1.5969 in.
40.411 to 40.450 mm
1.5910 to 1.5925 in.
0.350 mm
0.014 in.
–
–
Differential Case Cover Bore to Differential
Side Gear Boss
• Differential Case Cover Bore
• Differential Side Gear Boss
Clearance
I.D.
O.D.
0.090 to 0.169 mm
0.00355 to 0.00665 in.
40.540 to 40.580 mm
1.5961 to 1.5976 in.
40.411 to 40.450 mm
1.5910 to 1.5925 in.
0.350 mm
0.014 in.
–
–
Differential Pinion Shaft to Differential
Pinion
• Differential Pinion Shaft
• Differential Pinion
Clearance
O.D.
I.D.
0.0800 to 0.122 mm
0.00315 to 0.00480 in.
19.959 to 19.980 mm
0.78579 to 0.78661 in.
20.060 to 20.081 mm
0.78977 to 0.79059 in.
0.25 mm
0.0098 in.
–
–
Differential Pinion to Differential Side Gear Backlash 0.15 to 0.30 mm
0.0059 to 0.011 in.
0.4 mm
0.02 in.
