Xerox Phaser 6600 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
5-33
Parts List 13.1 Bypass Tray
Item Name Part Number
1 Bearing Dup (Duplex Bearing) —
2 Roll Assy TA1 (TA1 Roller Assembly) —
3 Roll Assy TA2 (TA2 Roller Assembly) —
4Gear TA 1 —
5Spacer TA2 —
6Bearing TA —
7Gear Turn —
8 Guide MSI R (Right Bypass Tray Guide) —
9 Guide MSI L (Left Bypass Tray Guide) —
98 Kit Roll Assy 1 (with1,2,6,7) (Roller Assembly Kit 1) 604K73890
99 Kit Roll Assy 2 (with1,3-7) (Roller Assembly Kit 2) 604K73900

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
