Xerox Phaser 6600 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-45
Xerographic
MCU Board
PL18.1.13
P/J12
1
2
3
P/J121
4
3
SG
CLOCK
CRUM
Connector
Assembly
PL8.1.1
2
14
+3.3VDC
DATA
Imaging Unit - Y
PL8.1.2
CRUM
5
6
7
P/J122
4
3
CRUM
Connector
Assembly
PL8.1.1
2
18
Imaging Unit - M
PL8.1.3
CRUM
13
14
15
P/J124
4
3
CRUM
Connector
Assembly
PL8.1.1
2
116
Imaging Unit - K
PL8.1.5
CRUM
9
10
11
P/J123
4
3
CRUM
Connector
Assembly
PL8.1.1
2
112
Imaging Unit - C
PL8.1.4
CRUM
+3.3VDC
SG
CLOCK
+3.3VDC
DATA
SG
CLOCK
+3.3VDC
DATA
SG
CLOCK
+3.3VDC
DATA
P/J13
1
2
3
J131
5
P131
1
2
3
4
3
J132
5
4
3
+5VDC
CTD VOUT
LED ON
4
5
4
5
2
1
CTD Sensor Assembly
PL6.1.14
2
1
CTD VMONTOR
SG
CTD
Sensor
+5VDC
EEPROM Board
PL18.1.43
P/J27
11
12
13
14
P/J251
4
3
2
1
DATA
CLOCK
+3.3VDC
SG
+3.3VDC
Registration Harness Assembly
PL15.2.8
Transfer CRUM Connector Assembly
PL8.1.8
Main Harness Assembly
PL18.2.3
s6600-229

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
