Xerox Phaser 6600 Service Manual

Wiring
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
7-30
AC Power
MCU Board
PL18.1.13
AC Inlet
PL18.1.31
LINE
Neut
Main
Switch
LVPS
PL18.1.34
P/J48
1
2
3
P/J503
1
2
3
4
Main Fan
PL4.1.13
ON
RTN
ALRM
1
2
P/J42
3
1
2
3
P/J41
4
Rear Interlock
Switch
PL14.1.3
Door Interlock
Switch
PL19.1.30
P/J43
2
1
SG
LD 5V
ON/OFF
STBY
+5VDC
10
9
8
P/J501
7
FAN
Drive
6
5
4
P/J501
12
11
3
1
P/J40
6
5
216
2
P/J30
1
17
I/L +24VDC
I/L +24VDC
RTN
2
3
4
P/J509
1
RTN
RTN
To Drive
To ROS
To IP Board
To Fuser
N.C.
P/J29
6
9
8
7
12
P/J29
11
10
15
14
13
REAR IL
DOOR IL
FAN LOW
FAN STOP
FAN ALRM
+3.3VDC
POWER ON
SG
SG
+5VDC
I/L
+24VDC
+3.3VDC
+5VDC
A
From IP Board
+3.3VDC
+24VDC
B
I/L +24VDC
I/L +24VDC
I/L +24VDC
4
3
2
1
+5VDC
SG
P/J29
18
19
+5VDC
SG
20
WASTE BOX FULL SENSED SIGNAL
P/J203
3
2
1
Toner Full Sensor
PL4.1.17
+5VDC
Top Harness Assembly
PL18.2.5
P/J507
1
2
P/J5071
1
2
Top Harness Assembly
PL18.2.5
To ROS
+24VDC
RTN
s6600-213
+5VDC

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
