Connection Details
This table lists the thirteen wiring diagrams and the details of the connections shown in each diagram.
Except for the Controllers, diagrams 1-12 are the same for the MFP and SFP; diagram 13 covers the
Scanner and applies only to the MFP.
Diagram Connection Details
1 AC Power Connections of LVPS with MCU Board.
Connections of AC IN Assembly with LVPS.
Connections of Main Fan with LVPS.
Connections of Rear Interlock Switch with LVPS.
Connections of Door Interlock Switch with LVPS.
Connections of MCU Board with Toner Full Sensor.
2 Fuser Connections of FUSING Assembly with LVPS.
Connections of FUSING Assembly with MCU Board.
Connections of LVPS with MCU Board.
3 Drive Connections of DRIVE Assembly with MCU Board.
Connections of DRIVE Assembly with LVPS.
4 Bypass Tray
(MSI)
Connections of Bypass Tray Sensor with MCU Board.
Connections of Bypass Tray No Paper Sensor with MCU Board.
Connections of DRIVE Assembly with MCU Board.
Connections of Bypass Tray Feed Solenoid with MCU Board.
5 Laser Unit Connections of Laser Unit with MCU Board.
Connections of Laser Unit with PWBA LVPS.
6 SFP Controller Connections of IP Board with MCU Board.
Connections of IP Board with LVPS.
Connections of IP Board with Laser Unit.
Connections of IP Board with Control Panel.
Connections of IP Board with USB Bracket Assembly.
6 MFP Controller Connections of IP Board with MCU Board.
Connections of IP Board with LVPS.
Connections of IP Board with Laser Unit.
Connections of IP Board with FAX Board.
Connections of IP Board with USB Hub Board.
Connections of USB Hub Board with Control Panel Assembly .
7 Paper Transport Connections of Regi Clutch with MCU Board.
Connections of Regi Chute Assembly with MCU Board.
Connections of Feed Clutch with MCU Board.
Connections of Duplex Clutch with MCU Board.
8 HVPS Connections of HVPS XERO DEVE with HVPS TR.
Connections of HVPS XERO DEVE with MCU Board.
