Xerox Phaser 6600 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-43
HVPS
Development HVPS
Board
PL18.1.14
Transfer Roller
BCR (Y)
Deve (Color)
BCR (M)
BCR (C)
1st BTR (Y)
1st BTR (M)
1st BTR (C)
1st BTR (K)
Transfer Roller
Drum Y
Drum M
Drum C
Drum K
MCU Board
PL18.1.13
P/J182
1
2
I-MONITOR TR2
3
4
DA TR2
DA TR2 CLN
5
DA TR1 K
6
7
+3V REF
8
9
10
CLOCK1
I/L +24VDC
11
P/J1821
11
10
9
8
7
6
5
4
3
2
1
RTN
Transfer HVPS
Board
PL18.1.28
P/J18
1
2
DA DO
CLOCK 1
3
4
DA DI
I MONITER
5
+3VREF
6
7
CLOCK 2
8
9
10
CLOCK 3
I/L +24VDC
RTN
11
12
P/J181
1
2
3
4
5
6
7
8
9
10
11
12
DA CLOCK
DA LD
I/L +24VDC
RTN
I/L +24VDC
13 13
SG
+3VDC
DA TR1 CLR
CLOCK3
BCR (K)
Deve (K)
HVPS Harness Assembly
PL18.2.6
MCU-HVPS Flat Flex Cable
PL18.2.7
s6600-228

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
