Xerox Phaser 6600 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-33
Drive
MCU Board
PL18.1.13
P/J17
1
2
MAIN ALARM MOT
MAIN REF CLOCK
3
4
MAIN START/STOP
5
MAIN GAIN CHANGE
SG
P/J171
5
4
3
2
1
Drive Assembly
PL3.1.1
LVPS
PL18.1.34
P/J33
1
2
DEVE ALARM MOT
3
4
5
6
7
8
+24VDC
P/J331
9
7
6
5
4
3
2
1
P/J509
4
3
RTN
I/L +24VDC
P/J312
1
2
P/J311
1
2
I/L +24VDC
RTN
2
1
I/L +24VDC
Main Motor
8
RTN
9
+24VDC
RTN
SG
DEVE START/STOP
DEVE START/STOP
DEVE GAIN CHANGE
Developer Motor
6
7
SUB ALARM MOT
SUB REF CLOCK
8
9
SUB START/STOP
10
SUB GAIN CHANGE
SG
P/J172
5
4
3
2
1
Paper Transport
Motor
+24VDC
Top Harness Assembly
PL18.2.5
Drive Harness Assembly
PL18.2.2
s6600-222
M
M
M

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
