Section 8.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 111 of 220
8.18.3. LIH NOISE (LAST IMAGE HOLD NOISE)
The LIH Noise reduction function reduces noise in the image when the radiation switch
is released. It is used to reduce noise and distortions that arise from the movement of the
C-Arm or patient during a fluoroscopic procedure. It is not a post-processing function
and cannot be used to change a previously stored image.
The system may be configured to apply low noise reduction for live images and a highe
level of noise reduction when the foot switch is released.
There are four LIH setting available: LOW, MED, HIGH, and OFF. If you do not wish
to have the image displayed on the monitor after the foot switch is released, press the
LIH Noise button several times until the message “LIH OFF” is displayed on the righ
monitor and the button is not highlighted in yellow.
NOTE:
The LIH function can be set to a default value in the Service Menu. This must be
performed by certified Service personnel.
8.19 AUTO FUNCTIONS
The Auto function has two modes of operation. You can configure the ZIEHM
QUANTUM so that a new image will be stored or transferred automatically as soon as
you terminate radiation.
Simply press the Auto Function button to open all the auto functions available for the
articular system configuration.
NOTE:
Some of the Auto functions may not be available depending on the configuration of
your system and optional features that may or may not be available on a particular
system model.
8.19.1. SETTING AUTO STORE:
To activate the Auto store function, do the following:
1) Press the Auto Function button. The Auto store function buttons will be displayed in a
row.
2) Select Auto Store, the Auto Store button is highlighted in yellow. The un-selected buttons
will then close.
Additional activation of Fluoroscopic radiation will save a new image automatically as soon as
the user release the foot or hand switch.
When Active Auto Function button is indicated by yellow color, and is indicated by a small
message below and to the right of the image on the touch screen panel.
To deactivate the Auto Store function, do the following:
